The VGA^ok is a small handheld VGA video signal generator and tester that outputs a simple color bar test pattern for the purpose of checking projectors, cables, monitors, and other related devices. It is intended for when you need to check that you have all of the RGBHV lines to a VGA input.

The VGA^ok is battery operated at lightweight, perfect for portable use. This signal generator can be helpful for general troubleshooting and projector and display set up for A/V applications; however it is not intended to replace test patterns for projector calibration from a professional unit like a Barco/Folsom ImagePRO.

The VGA^ok currently supports three output sizes covering basic common uses:

• 1024 x 768 4:3
• 1280 x 1024 5:4
• 1280 x 720 16:9

The VGA^ok also comes programmed with two lines of text to identify the owner of the unit. Typically these are your name and your phone number, although just about any text could be programmed, such as company name and web address.

The VGA^ok is powered by a 9 volt battery inside a black ABS plastic case, and is operated by a single push button. The unit is powered up by holding the button for 3 seconds, and there is a blue LED power indicator in the center of the button. After the unit is powered up, pressing the button again will switch to the next resolution. The unit will power off automatically 2 minutes after power up, or after the last resolution change.

Approximate Size:
2-3/4" x 1-1/4" x 5"

Order now!
Please allow 2-4 weeks for delivery at this time.

Price: $100 USD
US Shipping $5 USD
International Shipping $28/$32 USD based on location

Please contact us for orders greater than 1 unit.

Price includes:

• VGA^OK Signal Generator
• custom data programing
• Duracell Procell 9 volt battery
• Ripoffs brand clip-on holster

1024 x 768

1280 x 1024

1280 x 720
