There are currently no plans to make any additional units at this time.

Possible Alternative VGA testers:

Apple 4th Gen iPod Touch $229 & VGA Adapter $29 & TekCraze iTestGen Pro $4 -Total around $265

AV-Link PG-V1 available from Markertek for around $285US

Black Box PG-VGA for around $400US

Possible HDMI/DVI testers:

AV-Link PG-H1 available from Markertek for around $350US

Black Box PG-DIG for around $500US


vgaOK Different Views

vgaOK Side View vgaOK Frront View vgaOK Back View vgaOK Back View B vgaOK Holster

The VGAok is a small handheld VGA video signal generator and tester that outputs a simple color bar test pattern for the purpose of checking projectors, cables, monitors, and other related devices. It is intended for when you need to check that you have all of the RGBHV lines to a VGA input.

The VGAok is battery operated at lightweight, perfect for portable use. This signal generator can be helpful for general troubleshooting and projector and display set up for A/V applications; however it is not intended to replace test patterns for projector calibration from a professional unit like a Barco/Folsom ImagePRO.

The VGAok currently supports three output sizes covering basic common uses:

  • 1024 x 768 4:3
  • 1280 x 1024 5:4
  • 1280 x 720 16:9

The VGAok also comes programmed with two lines of text to identify the owner of the unit. Typically these are your name and your phone number, although just about any text could be programmed, such as company name and web address.

The VGAok is powered by a 9 volt battery inside a black ABS plastic case, and is operated by a single push button. The unit is powered up by holding the button for 3 seconds, and there is a blue LED power indicator in the center of the button. After the unit is powered up, pressing the button again will switch to the next resolution. The unit will power off automatically 2 minutes after power up, or after the last resolution change.

Approximate Size:
2-3/4" x 1-1/4" x 5"

Currently Not Available.

Price: $200 USD plus shipping via USPS based on location

Price includes:

  • VGAOK Signal Generator
  • custom data programing
  • Duracell Procell 9 volt battery
  • Ripoffs brand clip-on holster
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
1280 x 720
1280 x 720
